220v to 110v converter Features with the following specifications:
| 220v to 110v converter performance index input | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Rated working voltage range | - | 110/220 | - | Vac | - |
| Input voltage range | 80 | 220 | 300 | Vac | Three-phase five-wire input phase to phase 380V / relative zero line 220VAC |
| Output voltage range | - | 110 | - | Vdc | - |
| Battery input | - | 117 | - | Vdc | Battery pack’s positive and negative in parallel with DC output of rectifier module (polarity consistent) |
This system is designed and optimized for demanding industrial environments, including electrical substations, power plants, hydropower stations, and switching stations.
The module features advanced DSP (Digital Signal Processing) control technology. This ensures high-accuracy voltage and current regulation, a low ripple coefficient, and excellent overall reliability.
It adopts standard CAN communication mode between the module and the upper-level equipment, executing a pure software flow for data sharing.
While the rated working voltage is 110/220Vac, the system operates across a wide input voltage range of 80Vac to 300Vac, ensuring compatibility with varying input parameters.
Yes, the battery pack's positive and negative terminals can be connected in parallel with the DC output of the rectifier module. Please ensure the polarity is strictly consistent during installation.
