220v Ac to 24V Rectifier Features with the following specifications:
The 220v Ac to 24V Dc Power Supply comprises the AC input distribution, rectification, DC output distribution, and monitoring system. The four parts are in turn made up of different components as shown below:
- AC input distribution: AC distribution cabinets.
- Rectification: red insulation diodes.
- DC output distribution: diodectifiers an chain, insulation status detector, switching branches (connected to the switching bus), and control branches (connected to the control bus).
- Monitoring system: power control unit (PCU) and power distribution monitoring box.
| 24V Rectifier input |
| Parameter |
Min. |
Rated |
Max. |
Unit |
Note |
| Rated working voltage range |
|
117 |
|
VAC |
|
| Input voltage range |
80 |
110 |
300 |
VDC |
|
| Input frequency |
45 |
50 |
65 |
HZ |
|
| 24V Rectifier Output |
| Parameter |
Min. |
Rated |
Max. |
Unit |
Note |
| Output voltage range |
21 |
26.5 |
29 |
Vdc |
|
| Output current range |
0 |
|
60 |
A |
|
| Source change rate |
|
≤±0.5% |
|
|
|
| Load change rate |
|
≤±0.5% |
|
|
|
| Temperature coefficient |
|
150PPm/℃ |
|
|
|
| Peak ripple voltage |
|
Vpp≤100mV |
|
|
|
| Efficiency |
|
≥92% |
|
|
|
