• Active power factor compensation technology is adopted for 12v dc rectifier, power factor up to 0.99.
• Wide input voltage range, operating normally between 90 ~ 290Vac / 100-400Vdc.
• DC power system for CCTV adopts full bridge soft switching technology, efficiency can reach above 92%.
• Perfect battery management: low voltage load disconnect (LVLD) and low voltage battery disconnect (LVBD) to achieve temperature compensation, automatic float control, automatic voltage regulator, battery capacity calculation, online battery test function.
• 120v to 12v rectifier adopts no damage hot insert and pull technology, replacement time less than 1min.
• Network design, providing a variety of communication interfaces (for example: RS485, SNMP, MODBUS dry contact), flexible networking can achieve local and remote monitoring, unattended. Perfect AC and DC side lightning protection design used in multi thunderstorm area.
• Complete fault protection, fault alarm function.
• Comprehensive operation and maintenance, and can be mounted against the wall, saving space effectively.
• Ultra-low radiation. Adopt advanced electromagnetic compatibility design, the rectifier module can meet requirements for conducted and radiated interference of "the communication power equipment electromagnetic compatibility Limits and methods of measurement".
• Safe and reliable. System design in full compliance with safety standards EN60950 and GB4943.

Dimensions: 482.6mm(W) × 300mm(D) × 43.6mm(H)
