Features with the following specifications:
The power system comprises the AC input distribution, rectification, DC output distribution, and monitoring system. The four parts are in turn made up of different components as shown below:
Input voltage: 220VAC
Output voltage: 110Vdc 20A / 220V 10A
Output power: 2900W (176VAC~264VAC Input) / 1200W (90VAC~175VAC Input)
| 110V DC Power Supply Performance Index Input | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Rated working voltage range | - | 110/220 | - | Vac | - |
| Input voltage range | 90 | 220 | 264 | Vac | Three-phase five-wire input phase to phase 380V / relative zero line 220VAC |
| Input frequency | 45 | 50 | 65 | Hz | - |
| Power Factor | - | - | - | - | ≥0.98 @ 220VAC @ 117V / 20A |
| 110V DC Power Supply Performance Index Output | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Output voltage range | 100 | 117 | 156 | Vdc | 117VDC, 99~143V adjustable |
| Output current range (max. current) | 0 | - | 20 | A | Input 170 ~ 285VAC, when the input voltage is below 170VAC, output at derating manner. |
| Current Sharing | - | ±5% | - | - | - |
| Output Protection | - | - | - | - | Over voltage protection, Under voltage protection, Over temperature protection, Hot-swappable Internal failure isolated diode, Short circuit protection |
