EVS Powers
1 / 5
If the output voltage exceeds the preset value, the rectifier will automatically shut down. The overvoltage shutdown voltage is adjustable and is set at the factory.
When quickly plugging and unplugging modules, ensure the module is fully discharged. Observe the fan rotation after unplugging until it stops before inserting the module again.
During rectifier startup, the input surge current peak is limited to no more than 2 times the maximum input current. The voltage and current rise slowly from zero for a soft load characteristic.
At maximum operating temperature, the rectifier gradually reduces output current. In extreme conditions, it shuts down completely and auto-restarts once temperatures normalize.
Equipped with internal reverse polarity protection fuses and diodes to provide timely and effective component protection.
Features active current sharing when multiple rectifiers are shared. Smart fan cooling adjusts speed based on internal temperature, reducing noise and dust build-up.
| Specification Item | Value / Details |
|---|---|
| Input Voltage | 48VDC |
| Output Voltage | 200-750VDC |
| Application | Industry, Battery Charging, Machines, Industrial Equipment |
| Efficiency | 0.92 |
| Protection | Over Power, Overloading, Overvoltage, and Overcurrent Protection |
| Model Number | 38015 |
| Output Type | Single Phase |
| Output Frequency | 50Hz/60Hz |
| Output Current | 15A |
| Type | DC-DC Boost Converter |
We ensure strict quality control by always conducting a pre-production sample test before starting mass production, followed by a comprehensive final inspection of all units before shipment.
The product lineup includes switching power supplies, power inverters, DC-DC converters, rectifier module power systems, and specialized battery power chargers.
This converter features advanced protection systems, including Over Power Protection, Overloading Protection, Overvoltage Protection, Overcurrent Protection, and internal Reverse Polarity Protection.
When internal temperatures rise too high, the rectifier automatically reduces the output current. In extreme conditions, it will shut down completely and auto-restart once normal operating temperatures are restored.
Accepted delivery terms include FOB, CFR, CIF, EXW, DDP, DDU, and Express Delivery. Supported payment methods include T/T, Credit Card, PayPal, and Western Union in multiple currencies like USD, EUR, and HKD.
The system continuously monitors internal and ambient temperatures to adjust fan speed dynamically. This optimizes cooling while reducing noise, dust accumulation, and power consumption.
