EVS Powers
1 / 5
Features with the following specifications:
| Input Specification | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Rated working voltage range | - | 110/220 | - | Vac | - |
| Input voltage range | 90 | 220 | 290 | Vac | Three-phase five-wire input phase to phase 380V / relative zero line 220VAC |
| Input frequency | 43 | 50 | 67 | Hz | - |
| Battery input | 43.2 | 53.5 | 58 | Vdc | Battery pack’s positive and negative in parallel with DC output of rectifier module (polarity consistent) |
| Output Specification | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Output voltage range | 42 | 53.5 | 58 | Vdc | - |
| Output current range (max. current) | 0 | - | 30 | A | Input 170 ~ 285VAC, when the input voltage is below 170VAC, output at derating manner. |
| Regulation accuracy | - | - | ±1 | % | - |
| Load regulation | - | - | ±1 | % | - |
| Source regulation | - | - | ±1 | % | - |
| Current sharing regulation | - | - | ±5 | % | - |
| Battery output | - | - | - | A | - |
| Ripple (peak – peak value) | - | - | 200 | mv | Network 20MHz testing. |
| Output efficiency | 91 | 93 | - | % | 220Vac Input |
| Protection Specification | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Input over voltage protection | 300 | - | - | Vac | Self recovery |
| Input over voltage protection recover | 290 | - | - | Vac | - |
| Input low voltage protection | - | - | 85 | Vac | Self recovery |
| Input low voltage protection recover | - | - | 90 | Vac | - |
| Output over voltage protection | 58.5 | 59 | 60.5 | Vdc | Locked |
| Output short-circuit protection | - | - | - | - | Without battery case, can be short-circuit for long time, can self recovery |
