| DC220V Series | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Rated Power | 1KW | 2KW | 3KW | 4KW | 5KW | 6KW | 8KW | 10KW | 12KW | |
| Rated DC Voltage | DC216V | |||||||||
| Battery Voltage Range | DC180-288V | Low voltage warning | 198V | |||||||
| Low voltage power outage | 189V (180-216V ADJ) | |||||||||
| Low voltage recovery | 243V | |||||||||
| High voltage power outage | 283.5V (274.5-288V ADJ) | |||||||||
| High voltage recovery | 279V | |||||||||
| Low voltage shutdown | 171Vdc | |||||||||
| DC Priority Type | Low voltage switching of battery to mains voltage point | 198V (189-229.5V) | ||||||||
| Return to the battery supply voltage point after sufficient supply | 234V (216-261V) | |||||||||
| Communication Input | Rated AC input voltage | AC220V | AC110V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Scope of communication input | 170-280Vac (UPS) 90-280Vac (APL) |
- | |||||||||||
| Voltage drop point due to under voltage of the municipal power supply | 170Vac±5V (UPS) 90Vac±5V (APL) |
- | |||||||||||
| Under voltage recovery point of municipal power supply | 180Vac±5V (UPS) 100Vac±5V (APL) |
- | |||||||||||
| Overvoltage and power failure voltage point of mains power | 280Vac±5V | - | |||||||||||
| Overvoltage recovery voltage point of mains power | 270Vac±5V | - | |||||||||||
| Communication input frequency | 50HZ/60HZ (ADJ) | ||||||||||||
| Frequency range | 40-65HZ | ||||||||||||
| Single mains power on function | Yes | ||||||||||||
| UPS Conversion Time | <5ms (UPS); <13ms (Electrical mode) | ||||||||||||
| AC Output | AC output voltage | 220/230/240Vac±3% ADJ | - | ||||||||||
| Communication output frequency | 50±1HZ / 60±1HZ | ||||||||||||
| Output waveform | Pure sine wave (full voltage range) | ||||||||||||
| Waveform distortion rate | ≤3% (Linear Load) | ||||||||||||
| Inverter peak efficiency | 95% | ||||||||||||
| Dynamic response | (0~100%) ≤5% | ||||||||||||
| Power factor | >0.9 | ||||||||||||
| Peak power (surge capability) | Twice the rated power in 3 seconds | ||||||||||||
| Idle power consumption (standby power consumption) | 30W | ||||||||||||
| Power derating | No derating (output power will not decrease with the decrease of battery voltage) | ||||||||||||
| Work Environment | Noise (1 meter) | ≤40dB | |||||||||||
| Environmental temperature for use | -40℃ ~ +50℃ | ||||||||||||
| Storage environment temperature | -40℃ ~ +70℃ | ||||||||||||
| Humidity | 0~90% | ||||||||||||
| Using altitude (m) | ≤5000 (If higher than 1000m, usage will be reduced by 10% per 1000m) | ||||||||||||
| Continuous running time | Can run continuously for a long time | ||||||||||||
| Cooling method | Temperature controlled variable speed fan for heat dissipation | ||||||||||||
| Mean time between failures | Not less than 100,000 hours | ||||||||||||
